P6-E, pushbuttons and indicators

Standard: IEC 60947-5-1

Rated voltage Ue (V): 230

Rated current In (A): 6

Conventional glowing current (A): 16

Frequency (Hz): 50/60

Modules (18 mm): 1

Utilization category: AC14, DC13

Degree of protection: IP20, with connected conductors

Conductor cross-sections

Solid and stranded (mm²): 1-10

Finely stranded with end sleeve (mm²): 1-4

Terminal tightening torque (N·m): 0.5

Ambient temperature (°C): -5 ~ +40, max. 95% humidity

Storage temperature (°C): -40 ~ +75

Connection Capacity (mm²): 1-16
