PQ61, Enclosed direct-on-line (DOL) starters

Standards: IEC 60947-4-1, IEC 60439-1

Rated working current (A): 09, 12, 18, 25, 32, 40, 50, 65, 80, 95

Rated operational voltage Ue (V): 690

Rated insulation voltage Ui (V): 690

Rated impulse withstand voltage Uimp (kV): 8

Rated frequency (Hz): 50/60

Control (2 pushbuttons mounted on enclosure cover):

1 green Start button “I”; 1 red Stop/Reset button “O”

Enclosure: PQ61-09/12/18 Double insulated, degree of protection IP65;

PQ61-25/32 Double insulated, degree of protection IP55;

PQ61-40/50/65/80/95 Metal, degree of protection IP65

5 Electrical life (× 10 times): 5

5 Mechanical life (× 10 times): 50

Matched AC contactor: PC61

Matched thermal overload relay: PTR61

Ambient air temperature (ºC): -5 to +40, max. 95 % humidity

Storage temperature (ºC): -40 ~ +75

Maximum operating altitude (meters): 2000
